Sheet Metal Laser Cutting

Offered by Feida Machinery factory, sheet metal laser cutting is a subtractive manufacturing process that uses a computer-controlled high-powered laser beam to vaporize or melt materials.

This technique makes fabricating components with intricate details easier, does not contaminate work pieces either, requires minimal operator intervention, and offers high-speed cutting.

We can cut many types of materials,each with its own features for different applications.These materials include carbon steel, stainless steel,aluminum alloy, brass, etc., which are discussed below.

Carbon steel can typically be cut up to 20mm in thickness, and over 30mm when using high-power equipment.

Stainless steel can usually be cut from 0.5mm to 16mm, and the cutting effect on thin plates is particularly good.

The maximum thickness of aluminum plate is generally between 6mm and 10mm, and it needs to be combined with specific gases to prevent oxidation.

The greater the thickness, the higher the requirements for equipment: ordinary medium and small power machines are suitable for cutting thin plates. If thick plates (such as carbon steel over 20mm) are to be cut, a high-power laser with a power of over 3,000 watts needs to be selected.

Application

As a precise processing method,sheet metal laser cutting can almost cut all materials, including two-dimensional or three-dimensional cutting of thin metal plates.It is extensively usd in various fields,including automotive manufacturing,aerospace, non-metallic materials,etc.

Some common questions

What are the advantages of sheet metal laser cutting?

It offers many advantages:precise cuts and designs,better utilization of sheet,versatile cutting,lower energy consumption,and damage-free cuts.

What are types of lasers for this technique?

There are three common types:CO2 lasers,fiber lasers,and crystal lasers.

How about the mode transportation?

Small batches will be delivered by express such as DHL, FedEx, TNT, UPS, etc,and large batches will be shipped by sea or air.
